2SK3397 N沟道MOSFET 30V 70A TO-252/D-PAK marking/标记 K3397 继电器驱动器/DC-DC转换器应用
| 最大源漏极电压Vds Drain-Source Voltage | 30V |
| 最大栅源极电压Vgs(±) Gate-Source Voltage | 20V |
| 最大漏极电流Id Drain Current | 70A |
| 源漏极导通电阻ΩRds DΩ/Ohmain-SouΩ/Ohmce On-State Ω/Ohmesistance | 4Ω/Ohm @35A,10V |
| 开启电压Vgs（th） Gate-Source Threshold Voltage | 1.5-3V |
| 耗散功率Pd Power Dissipation | 125W |
| Description & Applications | Features Relay Drive and DC-DC Converter Applications Motor Drive Applications Low drain-source ON resistance: RDS (ON)= 4.0 mΩ (typ.) High forward transfer admittance: |Yfs| = 110 S (typ.) Low leakage current: IDSS = 10 μA (max) (VDS = 30 V) Enhancement mode: Vth = 1.5 to 3.0 V (VDS = 10 V, ID = 1 mA) |
| 描述与应用 | 特性 继电器驱动器和DC-DC转换器应用 电机驱动应用 低漏源导通电阻RDS（ON）= 4.0mΩ（典型值） 高正向转移导纳：| YFS|=110 S（典型值） 低漏电流：IDSS= 10μA（最大值）（VDS= 30 V） 增强模式：VTH =1.5〜3.0 V（VDS=10V，ID= 1毫安） |
| 规格书PDF |
