可调电阻 3214J-1-202E 2KΩ/Ohm 3224-2K marking/标记 202
| 电阻值Resistance | 2KΩ/Ohm |
| 额定功率Power | 0.25W，1/4W |
| 容差Tolerance | ±10% |
| 温度系数Temperature Coefficient | ±100ppm/°C |
| 圈数Number of Turns | 5 |
| 调节类型Adjustment Type | 侧面调节 Side Adjustment |
| 端子类型Termination Style | J引线 J Lead |
| Description & Applications | ■ Surface Mount 4 mm Square / Multiturn Cermet / Industrial / Sealed ■ Sealed to withstand board wash processing ■ 4 mm design meets EIA/EIAJ/IPC/VECI SMD standard trimmer footprint ■3214 - 5-Turn Trimpot® Trimming Potentiometer |
| 描述与应用 | ■表面贴装4毫米广场/多圈金属陶瓷/工业/密封 ■密封承受冲洗电路板处理 ■4毫米的设计符合EIA/ EIAJ/ IPC / VECI的的 SMD标准微调足迹 ■3214 - 5圈器系列Trimpot®微调电位器 |
| 规格书PDF |
