CL2431VS 电压基准电源IC 2.5V~18V SOT-23 marking/标记 Z8A5 精密可调并联参考
| 参考类型Reference Type | |
| 输出电压VoVoltage - Output | 2.5V~18V |
| 误差Tolerance | ±1% |
| 温度系数Temperature Coefficient | 30ppm/°C |
| 输入电压Voltage - Input | 2.5V~18V |
| 阴极电流Current - Cathode | 1mA |
| 输出电流IOUTCurrent - Output | 10mA |
| Description & Applications | FEATURES •Precision Adjustable Shunt Reference •Temperature-Compensated: 30ppm/oC •Trimmed 0.5% Bandgap Reference •Internal Amplifier with 100mA Capability •Temperature Range: Extended to 0 to 105oC •Low Frequency Dynamic Output Impedance: < 150mΩ •Low Output Noise •SOT-23 Replacement for TL431 |
| 描述与应用 | 特点 •精密可调并联参考 •温度补偿：30ppm/oC， •边0.5％的带隙参考 •内部放大器，具有100mA能力 扩展到0至105℃温度范围： •低频率的动态输出阻抗：150MΩ •低输出噪声 •SOT-23更换为TL431 |
| 规格书PDF |
