SBT2907AU PNP三极管 -60V -600mA/- 0.6A 200MHz 100 -400mV/-0.4V SOT-323/SC-70 marking/标记 F2 低漏电流/开关
| 集电极-基极反向击穿电压V(BR)CBOCollector-Base Voltage(VCBO) | -60V |
| 集电极-发射极反向击穿电压V(BR)CEOCollector-Emitter Voltage(VCEO) | −60V |
| 集电极连续输出电流ICCollector Current(IC) | −600mA/- 0.6A |
| 截止频率fTTranstion Frequency(fT) | 200MHz |
| 直流电流增益hFEDC Current Gain(hFE) | 100 |
| 管压降VCE（sat）Collector-Emitter SaturationVoltage | -400mV/-0.4V |
| 耗散功率PcPoWer Dissipation | 350mW/0.35W |
| Description & Applications | PNP Silicon Transistor Descriptions • General purpose application • Switching application Features • Low Leakage current • Low collector saturation voltage enabling low voltage operation • Complementary pair with SBT2222AU |
| 描述与应用 | PNP硅晶体管 简述 •通用应用 •开关应用 特点 •低漏电流 •低集电极饱和电压，使低电压操作 •SBT2222AU互补配对 |
| 规格书PDF |
