MMBTA92 PNP三极管 -300V -500mA/-0.5A 50MHz 40 -500mV/-0.5V SOT-23/SC-59 marking/标记 YV 高电压
| 集电极-基极反向击穿电压V(BR)CBOCollector-Base Voltage(VCBO) | -300V |
| 集电极-发射极反向击穿电压V(BR)CEOCollector-Emitter Voltage(VCEO) | −300V |
| 集电极连续输出电流ICCollector Current(IC) | −500mA/-0.5A |
| 截止频率fTTranstion Frequency(fT) | 50MHz |
| 直流电流增益hFEDC Current Gain(hFE) | 40 |
| 管压降VCE（sat）Collector-Emitter SaturationVoltage | −500mV/-0.5V |
| 耗散功率PcPoWer Dissipation | 350mW/0.35W |
| Description & Applications | SMALL SIGNAL PNP TRANSISTOR SILICON EPITAXIAL PLANAR PNP HIGH VOLTAGE TRANSISTOR MINIATURE SOT-23 PLASTIC PACKAGE FOR SURFACE MOUNTING CIRCUITS TAPE AND REEL PACKING THE NPN COMPLEMENTARY TYPE IS MMBTA42 APPLICATIONS VIDEO AMPLIFIER CIRCUITS (RGB CATHODE CURRENT CONTROL) TELEPHONE WIRELINE INTERFACE (HOOK SWITCHES, DIALER CIRCUITS) |
| 描述与应用 | 小信号PNP晶体管 硅外延平面PNP高压晶体管 微型SOT-23塑料包装 用于表面安装电路 卷带式包装 NPN互补型IS MMBTA42 应用 视频放大器电路（RGB阴极电流控制） 电话有线接口（钩开关，拨号器电路） |
| 规格书PDF |
