| Description & Applications | Features: • 2 EMI/RFI Bi–directional “Pi” Low–Pass Filters • ESD Protection Meets IEC6000–4–2, ±8 kV Contact Discharge • Diode Capacitance: 7 – 10 pF • Zener/Resistor Line Capacitance: 22 ±20% pF • Low Zener Diode Leakage: 1 A Maximum • Zener Breakdown Voltage; 6 – 8 Volts Benefits: • Designed to suppress EMI/RFI Noise in Systems Subjected to Electromagnetic Interference • Nominal Cutoff Frequency of 220 MHz (per Figure 2) • Small Package Size Minimizes Parasitic Inductance, Thus a More “Ideal” Low Pass Filtering Response Typical Applications: • Cellular Phones • Communication Systems • Computers • Portable Products with Input/Output Conductors |
