小功率电感 NL252018T-R12J 120nH/0.12UH 2520-R12j R12J
| 电感值Inductance | 120nH/0.12UH |
| 误差Tolerance | ±5% |
| 额定电流Current Rating | 550mA |
| 饱和电流Current - Saturation | |
| 不同频率时的Q值Q @ Frequency | 30 @ 25.2MHz |
| 自振谐频率SRFFrequency - Self Resonant | 700MHz |
| DC电阻DCRDC Resistance (DCR) | 0.3Ω/Ohm |
| 屏蔽Shielding | 屏蔽 Shielded |
| Description & Applications | NL Series NL2520 Type FEATURES • Utilizing a miniaturized winding structure, these products provide high Q characteristics. • Inductance tolerance is ±5 percent. |
| 描述与应用 | NL系列NL2520类型 特点 •利用一个微型绕组结构，高Q特性。 •电感容差为±5％。 |
| 规格书PDF |
