集成电路IC 或门 TC7SZ32F SOT-153/SMV marking/标记 J4

热销商品

产品描述
逻辑类型Logic Type或门 OR Gate
电路数Number of Circuits1
输入数Number of Inputs2
电源电压VccVoltage - Supply1.8v~5.5v
静态电流IqCurrent - Quiescent (Max)2uA
输出高,低电平电流Current - Output High, Low-24mA,24mA
低逻辑电平Logic Level - Low0.12v~0.25v
高逻辑电平Logic Level - High0.75v~0.88v
传播延迟时间@Vcc,CLMax Propagation Delay @ V, Max CL2.4ns @ 5V,50pF
Description & Applications2-Input OR Gate ;High output current : ±24 mA (min) at VCC = 3 V • Super high speed operation : tpd=2.4 ns (typ.) at VCC = 5 V, 50 pF • Operating voltage range : VCC = 1.8 to 5.5 V • 5.5-V tolerant inputs • 5.5-V power down protection output • Matches the performance of TC74LCX series when operated at 3.3- V VCC
描述与应用2输入或门;高输出电流:±24 mA(分钟)在VCC=3 V •超高速运转:TPD =2.4 ns(典型值) 在VCC = 5 V,50 pF的 •工作电压范围:VCC = 1.8至5.5 V •5.5-V宽容输入 •5.5-V断电保护输出 •操作时的性能相匹配的TC74LCX系列 3.3-V的VCC
规格书PDF
