TPS2015D 电源分配开关电源IC SOIC-8 marking/标记 2015D 配电开关
| 类型Type | 高端开关 high-side |
| 输出数Number of Outputs | 3 |
| Rds (On) | 80mΩ@5V |
| 内部开关Internal Switch(s) | 有 YES |
| 电流限制Current Limit | 1.1A~ |
| 电压 - 输入Voltage - Input | 4~7V |
| Description & Applications | •POWER DISTRIBUTION SWITCHES •95-mW Maximum (5-V Input) High-Side MOSFET Switch •Short-Circuit Protection and Thermal Protection •Logic Overcurrent Output •4-V to 7-V Operating Range •Enable Input Compatible With 3-V and 5-V Logic •Controlled Rise and Fall Times Limit Current Surges and Minimize EMI •Undervoltage Lockout Ensures That Switch is Off at Start-Up •10-mA Maximum Standby Current •Available in Space-Saving 8-Pin SOIC and 8-Pin PDIP •0°C to 125°C Operating Junction •Temperature Range |
| 描述与应用 | •配电开关 •95-mW最大（5-V输入）高边 MOSFET开关 •短路保护和热 保护 •逻辑过电流输出 •4-V到7 V工作电压范围 •启用3-V和5-V输入，兼容 逻辑 •控制上升和下降时间限制 浪涌电流和降低EMI •欠压锁定确保开关 关启动 •10 mA最大待机电流 •可节省空间的8引脚SOIC 8引脚PDIP •0°C到125°C工作结 •温度范围 |
| 规格书PDF |
