集成电路IC 模拟开关 PI3A3160ZGEX 1206 marking/标记 MNZ
| 开关配置Circuit | 2*单刀双掷 2*SPDT |
| 导通电阻On-State Resistance | 1.3Ω/Ohm |
| 电源电压Voltage - Supply | 1.5 V ~ 4.2 V |
| Description & Applications | 3.0V,0.4Ω SPDT Analog Switch The PI3A3160 is a fast Dual single-pole double-throw (SPDT) CMOS switch. It can be used as an analog switch or as a lowdelay bus switch. Specified over a wide operating power supply voltage range, the switch has an On-Resistance of 0.4Ω at 3.0V. Control inputs, IN, tolerates input drive signals up to 3.3V, independent of supply voltage. PI3A3160 is a lower voltage and On-Resistance replacement for the PI5A3158. CMOS Technology for Bus and Analog Applications Low On-Resistance: 0.4Ω (+2.7V Supply) Wide VCC Range: +1.5V to +3.6V Low Power Consumption : 5µW Rail-to-Rail switching throughout Signal Range Fast Switching Speed: 20ns max. at 3.3V High Off Isolation: –27dB at 100 KHz –41dB (100 KHz) Crosstalk Rejection Reduces Applications Cell Phones PDAs Portable Instrumentation Battery Powered Communications Computer Peripherals |
| 描述与应用 | 3.0V，0.4ΩSPDT模拟开关 PI3A3160是一个快速双单单刀双掷（SPDT） CMOS开关。它可以被用来作为模拟开关或一个总线lowdelay开关。指定在宽工作电源 电压范围，开关导通电阻 0.4Ω3.0V。 控制输入，在输入驱动信号，容忍到3.3V，与电源电压无关。 PI3A3160是一个较低的电压和导通电阻的替代 PI5A3158。 CMOS总线和模拟技术的应用 低导通电阻：0.4Ω（+2.7 V电源） 宽VCC范围：+1.5 V至+3.6 V 低功耗：5μW 整个信号范围轨到轨开关 开关速度快：20ns最大。在3.3V 高关断隔离：27分贝在100千赫 -41分贝（100千赫），串扰抑制降低 应用 手机 掌上电脑 便携式仪表 电池供电的通信 电脑周边 |
| 规格书PDF |
