光电耦合器 晶体管，光电输出 PS2501-1 SOP4
| 通道数Number of Channels | 1 |
| 输入类型Input Type | DC |
| 电压 - 隔离Voltage - Isolation | 5000Vrms |
| 电流传输比（最小值）Current Transfer Ratio (Min) | 80% @ 5mA |
| 电流传输比（最大值）Current Transfer Ratio (Max) | 600% @ 5mA |
| 电压 - 输出Voltage - Output | 80V |
| 电流 - 输出/通道Current - Output / Channel | 50mA |
| 电流 - DC 正向 (If)Current - DC Forward (If) | 80mA |
| Vce 饱和值（最大值）Vce Saturation (Max) | 0.3V |
| 输出类型Output Type | 晶体管 Transistor |
| Description & Applications | Features • PHOTOCOUPLER • HIGH ISOLATION VOLTAGE SINGLE TRANSISTOR TYPE MULTI PHOTOCOUPLER SERIES • High isolation voltage (BV = 5 000 Vr.m.s.) • High collector to emitter voltage (VCEO = 80 V) • High-speed switching (tr = 3 µs TYP., tf = 5 µs TYP.) • Ordering number of taping product: PS2501L-1-E3, E4, F3, F4, PS2501L-2-E3, E4 • UL approved: File No. E72422 (S) APPLICATIONS • Power supply • Telephone/FAX. • FA/OA equipment • Programmable logic controller |
| 描述与应用 | 特点 •光耦合器 •高隔离电压单晶体管型多光耦合器系列 •高隔离电压（BV =5000 Vr.m.s.） •高集电极到发射极电压（VCEO=80 V） •高速开关（TR =3μs典型值，：TF =5微秒TYP。） •录音产品订购数量：PS2501L-1-E3，E4，F3，F4，PS2501L-2-E3，E4 •UL批准：文件编号E72422（S） 应用 •电源 •电话/传真。 •FA/ OA设备 •可编程逻辑控制器 |
| 规格书PDF |
